GEPRC SPEEDX2 2306E Motor

Summary

The SPEEDX2 2306E motor features a sleek all-black design with blade-like protrusions that securely lock the propellers. Its extensive cutout structure enhances heat dissipation efficiency. Crafted from aerospace-grade aluminum using precision CNC machining, it is both lightweight and durable.

Feature

1. Reduced rotor-stator gap ensures rapid response for seamless freestyle flying.
2. The fresh all-black glossy design with extensive cutouts enhances heat dissipation for better performance.
3. Crafted from 7075 aerospace-grade aluminum with precision CNC machining for a lightweight design.

Specifications

• Model: SPEEDX2 2306E Motor
• KV: 1860
• Max Watt: 972.7W
• Peak Current: 39.18A
• Interphase Resistance: 83.17mΩ
• Propeller: 4-5inch
• Magnet: N52H
• Bearing: NMB/NSK
• Stator Configuration: 12N14P
• Dimension: 29*18.6mm
• Shaft Diameter: 5mm
• Shaft Length: 13.5mm
• Mounting Hole Size：16*16mm
• Wire Specification: 20AWG/150mm
• Compatible ESC: 40A/6S
• Input Voltage: 6S
• Winding: Single-strand copper winding
• Color: Black
• Weight：33.3g (including wire)
• Compatible Models: Suitable for 4inch-5inch racing FPV quads
•
