GEP-KX5 Elegant

SUMMARY

Our team keeps thinking that how to make a rack which is balanced both in competition and freestyle. Perhaps, GEP-KX5 can make you feel the good balance by its new and fresh design.

GEP-KX5 is wished to be designed as a rack which is quite elegant and graceful. This is the reason why it is named as “Elegant”.





For structure, “Elegant” has a most outstanding feature that the battery center is used as the balance point, which makes the gravity of the whole battery in the middle. Such a design will be good for turning because of its good hand-feeling. And it is not easy to draft. What’s more, the design will make the effort and power-supply to the four motors well-distributed; and the design will lower the calorific value of the motor but improve the use efficiency of the battery. Thanks to the big wheel base (243mm), TrueX design and a wide wheel base ratio, Freestyle can move flexibly, lowering the flow disturbing made by each propeller. Therefore, it can fly more stably and freely.





For materials, the carbon board is made of 3K pure carbon fire plates; the one-in-all high accurate CNC arm is equipped. The camera and video recorder base is made of high-strength aviation aluminum (type: 7075), which is processed in a high accurate way. By a fine docking with carbon board, the new design will have its hardness 50% higher than the traditional one, so that the device will not be easy to be hit and hurt, the pilots can be more worry-free. However, the whole weight of “Elegant” is only 115g.





For electronic equipment, “Elegant” is equipped with LED rear light board (including the buzzer, to be supported by CF/BF) and PDB distribution board when leaving the factory. By BEC (5/12v output) and integrating with XT60, it will be less difficult for the operators to do the assembly. “Elegant” uses YFS screws so that it is not easy to be rusted and the strength (grade 12.9) can meet the needs.

By now, we have spent almost one month testing “Elegant”, definitely, it is a good choice for Freestyle or racing assembly.

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-KX5 Elegant
Weight:115g
Wheelbase:243mm
Props Size: 5inch
Size:205*205mm
Arms board:4mm
Base board:2mm
Side board:1.0mm

Recommended

Flight Controller:F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC:20A-35A
Propeller:5inch
Battery: 3S 1300mAh ~ 4S 1500mAh

Features

  1. The battery is located above the arm, which shall be in the form of a symmetrical distribution. The center is in the middle of the whole machine. When flying, the pilot can have good hand feeling. The motor output is more balanced and more high efficient; the design lowers the risk of damaging the battery when being collapsed.
  2. Camera and the video recorder use #7075 aviation aluminum alloy, which is processed in a high accurate way (high accuracy CNC), making the whole machine good-looking and solid.
  3. The one-in-all high accurate CNC arm is made of 3K pure carbon fiber plates, whose structure is simple but solid. The arm is quite narrow (14mm) so the wind resistance will be smaller.
  4. The front part and rear part are supported by aluminum pieces, while the side board connects with the aluminum parts, making the structure solid and firm. Besides, such a structure can efficiently protect the electronic equipment inside the machine. The LED rear light board is fixed by a square aluminum post, where a buzzer for seeking the machine is available. Therefore, it is quite practical and good-looking.
  5. By True X structure, it is suitable for competition and freestyle fly.
  6. There are six 2812 rear lights and a bb sound. When flying, the lights are cool and the flight is easy to be found because of the buzzer.
  7. The motor rack has a stand-out design, which can protect the motor when there is a collision. There are spacing holes for motor wire, which will make the wiring easier and more convenient; the motor wires are tightly close to the arm bottom, which will not adversely affect the look but better protect the motor wires and ESC (electronic speed controller).
  8. The 2mm bottom board can well guarantee the flight control; also, it can protect the components from being damaged when collapsing and landing.
  9. YFS screws (strength: grade 12.9) can ensure a good hardness.
  10. One PDB distribution board with BEC (5/12v output) is available, integrating with XT60.

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

Aluminum frame

Support swift/swift2 HS1190 so on

True X

Freestyle & racing also nice

MOTOR SEAT

Make sure motor no easy broken

GOPRO SEAT

GoPro seat, no extra

Side board

Better protection of electronic devices

Led board

WS2812B led , Need BF/CF support

Antenna Seat

Better to protect the antenna

Rational layout

Easy building

Nice structure

The most reasonable structure

ALL PARTS

PHOTO ALBUM

Open post

GEP-HX2 Hummingbird

SUMMARY

Hummingbird, Small body, Speed and agility!

This is the GEP-HX2, nicknamed Hummingbirds, wheelbase 110 mm, for 2 inch props, You can flight in the small place, GEP-HX2 is very like a hummingbird, At least that's what our team thinks.

GEP-HX2 layout TRUE-X, So the pilot can easy any action, Prefect racing.GEP-HX2 full 3k carbon on all plates, YFS 12.9 class hardness screws. The side plate of the camera can protect the camera from being broken. GEP-HX2 support Micro Swift(recommended) and other CMOS Camera. This is perfect!

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-HX2 Hummingbird
Weight:17g
Wheelbase:110mm
Props Size: 2inch
Size:93*93mm
Main board:2mm
Side board:1.5mm

Recommended

Flight Controller:F3 / F4 /Naze32/ CC3D
Motors: 1104/ 1105/ 1106 /1306
ESC:10-15A
Propeller:2inch
Battery: 2S 450mAh ~ 3S 450mAh

Features

  1. Full 3K high strength carbon board to ensure that the frame is strong
  2. “True X” Make sure any flight action
  3. 0-50 degrees camera seat, Support use Micro Swift and Normal CMOS camera
  4. The arm use 7mm width, 2mm thickness, minimum drag coefficient
  5. Wheelbase 110mm, Air passage is easier
  6. YFS screws, 12.9 class of hardness
  7. Battery antiskid stick, Make sure the battery no lost
  8. The camera side plate, Make sure camera safety

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

CAMERA SEAT

Support Runcam Micro Swift and Normal Cmos

Camera protection plate

Lower the camera broken

Full 3k Carbon

Make sure body strong

Tenon structure

Make sure no easy broken

One Body Arms

Light weight And strong

Battery antiskid stick

Make sure the battery no lost.

GEP-MX5 ALL PARTS

PHOTO ALBUM

Open post

GEP-TSX5

SUMMARY

The frame is gep-tsx5, Named Viper.

GEP-TSX5 is made of 3K Carbon Fiber Quadcopter Frame plates and the Grand 12.9 YFS screw. The Stretch-X made it more adapted to the Racing. Our design teams decide to use 5mm(thickness) x 9mm(width) Arm to overcome wind resistance effectively. The motor seat is redesigned to a large extent to protect the motor. The camera seat works for most brands, Such as Runcam swift /swift2, Foxeer HS1190 and so on. The camera 20 to 60 degress. But I'd like to introduce the GoPro. 35-58 degress. Applies to most scenarios. Such as Racing and Freestyle.

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-TSX Viper
Weight:102g
Wheelbase:220mm
Props Size: 5inch
Size:210*170mm
Arms board:5mm
Top board:3mm
Other board:2mm

Recommended

Flight Controller:F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC:20A-35A
Propeller:5inch
Battery: 3S 1300mAh ~ 4S 1500mAh

Features

  1. All plate use 3k full Carbon, make sure strength
  2. Layout Stretch-X. High speed. Good apply to Racing or Freestyle
  3. The Arms is 9mm width and 5mm thickness, Overcome wind resistance effectively
  4. Redesign motor seat, Make sure motor no easy broken.
  5. Good side board design, good protection of the camera
  6. GoPro seat, 35 to 58 degress.
  7. Motor to motor is 220mm, Make sure the air unobstructed.
  8. YFS brand screw, 12.9 class hardness
  9. Battery antiskid stick, Make sure the battery no lost.
  10. The battery protection board can avoid the battery broken

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

CAMERA SEAT

Support swift/swift2 HS1190 so on

9mm WIDTH 5MM THICKNESS

Overcome wind resistance effectively

MOTOR SEAT

Make sure motor no easy broken

GOPRO SEAT

GoPro seat, 35 to 58 degress.

REASONABLE STRUCTURE

High intensity and low cost for pilot

PERFECT WITH SESSION

Make sure record is good

3mm THICKNESS TOP PLATE

 Fragile plate but stronger

THE BATTERY PROTECTION BOARD

Battery not easy broken

YFS SCREW

12.9 Class hardness

GEP-MX5 ALL PARTS

PHOTO ALBUM

Open post

GEP-MX3

SUMMARY

The sparrow, yes, he is called the sparrow. The sparrow is small all-sided.

GEP-MX is a mini frame. We call it little sparrows, small and flexible. Sparrow best apply 3nch blade, there will be two versions. GEP-MX3(True X) is suitable for all kinds of action, GEP-MSX (Stretch X) suitable for racing, Move very speed and flexibly.

Frame body ultralight use 3k carbon plate, thickness of 3 mm, combining aviation aluminum # 7075 fuselage, integral collocation, is very perfect. The pilot can be in a small space high-speed flight. Although small, but very resistant to fall off. It's worth noting that can perfect match RUNCAM Swift-Mini and Micro Swift lens. In order to let players precisely control their own flight Angle, our team used a laser carving scale, players can adjust Angle to his habit of flight, and we also radium vulture GEPRC anti-counterfeiting LOGO. Flight control pitch has two options, respectively is the commonly used 20 * 20 mm and 30.5 * 30.5 mm, The pilot can according to their own needs to be installed. Rack also equipped with LED taillights, available to the competition. Single stand about 39 g (do not include the electronic equipment). Clearly, he can make you amazing.

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name: GEP-MX3 Sparrow
Weight: 39g
Wheelbase: 139mm
Props Size: 3inch
Size: 120*120mm
Main board:3mm
Other board:1.5mm

Recommended

Flight Controller: F3 / F4 / Naze32 /CC3D
Motors: 1306/1406/1407/1408
ESC: 15A-20A
Propeller: 3inch
Battery: 3S 550-850mAh ~ 4S 550-850mAh

SPECIFICATIONS

Name: GEP-MSX3 Sparrow
Weight: 41g
Wheelbase: 145mm
Props Size: 3inch
Size: 110*145mm
Main board:3mm
Other board:1.5mm

Recommended

Flight Controller: F3 / F4 / Naze32 /CC3D
Motors: 1306/1406/1407/1408
ESC: 15A-20A
Propeller: 3inch
Battery: 3S 550-850mAh ~ 4S 550-850mAh

Features

  1. Aviation aluminum # 7075 high-precision CNC fuselage, very strong resistance to blast
  2. 3k carbon high strength plate to ensure frame
  3. True X and Strectch X Two design structure
  4. Can be perfectly matched RUNCAM Swift Mini and Micro Swift lens
  5. The specially designed gopro, use cable tie can be simple to use
  6. Aluminum fuselage protection design, can be very good to protect the Camera
  7. Hardness YFS screws, 12.9 level
  8. Set aside two flight control interface (20 * 20 mm and 30.5 * 30.5 mm), have more selective
  9. LED taillights, essential competition
  10. The laser carving degree Angle, allows players to precisely control Angle

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

# 7075 AVIATION ALUMINUM ALLOY

Ensure strong high strength structure

MICRO SWIFT

SUPPORT RUNCAM MICRO SWIFT

SWIFT MINI

SUPPORT RUNCAM SWIFT MINI

WS2812 LED

NEED FC SUPPORT(BF/CF)

GOPRO SEAT

SUPPORT GOPRO 1-5 AND SESSION

3mm THICKNESS

3mm THICKNESS TO BE CARBON BODY

THE NEW DESIGN  ARM STRUCTURE

STRONG, ONLY FOR STRETCH X

TRUE X

FREESTYLE RACING OR OTHER

STRETCH X

RACING IS BEST

GEP-MX5 ALL PARTS

GEP-MSX5 ALL PARTS

PHOTO ALBUM

Open post

GEP-LSX

SUMMARY

The leopard, natural predators, running at a staggering rate

This is GEP - LSX5, Leopard(GEP-LX) derivatives, ‘S’ mean is stretching. This is more suitable for competition. High-speed forward flight and rapid roll have more advantages. GEP-LSX respectively with three kinds of specifications.GEP-LSX4 wheelbase 205 mm, suitable for 4inch propeller. GEP-LSX5 wheelbase 230 mm, suitable for 5inch propeller, GEP-LSX6 wheelbase 265 mm for 6inch propeller.

The frame use 3k ultra-light carbon plate + Aviation aluminum # 7075 body. To strengthen the four arm, we also design a fixed four arm of the aluminum alloy parts, it is not easy to make the machine arm shift.

We also equipped with A piece of PDB, take BEC output 5 v 3 A and 12V 0.5A.The frame all adopt the YFS screws, 12.9 magnitude

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-LSX4
Weight:109g
Wheelbase:205mm
Props Size: 4inch
Size:165*200mm
Arms board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 /F4  / Naze32 / CC3D
Motor: 2204/2205
Esc:20A-30A
Props:4inch
Battery:  3S 1300mAh ~ 4S 1300mAh

SPECIFICATIONS

Name:GEP-LSX5
Weight:114g
Wheelbase:230mm
Props Size: 5inch
Size:178*222mm
Arms board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC:20A-35A
Propeller:5inch
Battery:  3S 1300mAh ~ 4S 1500mAh

SPECIFICATIONS

Name:GEP-LSX6
Weight:123g
Wheelbase:265mm
Props Size: 6inch
Size:200*250mm
Arms board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC:30A-40A
Propeller:6inch
Battery:  3S 1300mAh ~ 4S 1800mAh

Features

1. Aviation aluminum # 7075 high-precision CNC fuselage, very strong resistance to blast
2. 3K high strength carbon board to ensure that the frame is strong
3. An aluminum alloy structure, binding the four machine arm will not shift
4. The structure of SX, suitable for racing
5. Reasonable gopro, runcam position, convenient video
6. 13.5 mm wide, 4 mm thick arm design, small wind resistance coefficient
7. 5 inch wheelbase 230 mm, 4 "wheelbase 205 mm, 6 inch wheelbase 265 mm, have wider air through
8. The YFS screws, 12.9 level of hardness
9. support HS1190 HS1170, Swift
10. The motor position widened, home is not easy to hit the motor
11. The camera is adjustable, 0 to 60 degrees
12. With the kits: a piece of PDB panels, integrated XT60, BEC (5/12v output)

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

# 7075 AVIATION ALUMINUM ALLOY

Ensure strong high strength structure

ARM FIXED PIECES

It is unshakable

COMPATIBLE WITH A VARIETY OF CAMERAS

Hs1177/Hs1190/Swift/Swift2

2MM THICK CAMERA PROTECTION BOARD

Use 3k high strength carbon plate

STRETCH "X" STRUCTURE

Is good for racing

FIXED THE ANTENNA SEAT

2 mm thickness to be used for fixed antenna

HIGH PRECISION CNC

Precise process to ensure safety

A LOW CENTER OF GRAVITY

The fuselage height only 45 mm

3 VERSION CHOICE

4inch,5inch,6inch

LARGE SPACE INSIDE

Don't worry about not enough space

BATTERY PROTECTION BOARD

Don't have to worry about battery is destroyed

TAIWAN YFS BRAND SCREW

12.9 level screw

ALL PARTS

PHOTO ALBUM

Open post

GEP-LX Leopard

SUMMARY

The leopard, natural predators, running at a staggering rate

This is the GEP-LX, also called ‘Leopard’, There are three kinds of specifications respectively. 4inch(wheelbase 195mm), 5inch(wheelbase 220mm), 6inch(wheelbase 255mm). The fuselage low center of gravity design.

The machine use 3k ultra-light carbon plate + Aviation aluminum # 7075 body. To strengthen the four arm, we also design a fixed four arm of the aluminum alloy parts, it is not easy to make the machine arm shift.

In order to perfect fit more lens, we presented two schemes of board. The optimum foxeer HS1190 models of cameras and 1 or 2 generation Runcam Swift models of cameras. We also equipped with A piece of PDB, take BEC output 5 v 3 A and 12V 0.5A.The frame all adopt the YFS screws, 12.9 magnitude

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-LX4 Leopard
Weight:109g
Wheelbase:195mm
Props Size: 4inch
Size:175*175mm
Arms board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 /F4  / Naze32 / CC3D
Motor: 2204/2205
Esc:20A-30A
Props:4inch
Battery:  3S 1300mAh ~ 4S 1300mAh

SPECIFICATIONS

Name:GEP-LX5 Leopard
Weight:114g
Wheelbase:220mm
Props Size: 5inch
Size:195*195mm
Arms board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC:20A-35A
Propeller:5inch
Battery:  3S 1300mAh ~ 4S 1500mAh

SPECIFICATIONS

Name:GEP-LX6 Leopard
Weight:123g
Wheelbase:220mm
Props Size: 6inch
Size:220*220mm
Arms board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 / F4 / Naze32 / CC3D
Motors: 2204/2205/2206/2305/2306
ESC:30A-40A
Propeller:6inch
Battery:  3S 1300mAh ~ 4S 1800mAh

Features

  1. Aviation aluminum # 7075 high-precision CNC fuselage, very strong resistance to blast
  2. 3K high strength carbon board to ensure that the frame is strong
  3. An aluminum alloy structure, binding the four machine arm will not shift
  4. “True X” Suitable for competition and Freestyle fancy flying
  5. Reasonable gopro, runcam position, convenient video
  6. 5 mm wide, 4 mm thick arm design, small wind resistance coefficient
  7. 5 inch wheelbase 220 mm, 4 "wheelbase 195 mm, 6 inch wheelbase 255 mm, have wider air through
  8. The YFS screws, 12.9 level of hardness
  9. Two sets of cameras side panel, support HS1190 HS1170, Swift, ovf lens, etc
  10. The motor position widened, home is not easy to hit the motor
  11. The camera is adjustable, 0 to 60 degrees
  12. With the kits: a piece of PDB panels, integrated XT60, BEC (5/12v output)

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

# 7075 AVIATION ALUMINUM ALLOY

Ensure strong high strength structure

ARM FIXED PIECES

It is unshakable

COMPATIBLE WITH A VARIETY OF CAMERAS

Hs1177/Hs1190/Swift/Swift2

2MM THICK CAMERA PROTECTION BOARD

Use 3k high strength carbon plate

TRUE "X" STRUCTURE

Is good for racing and freestyle

FIXED THE ANTENNA SEAT

2 mm thickness to be used for fixed antenna

HIGH PRECISION CNC

Precise process to ensure safety

A LOW CENTER OF GRAVITY

The fuselage height only 45 mm

3 VERSION CHOICE

4inch,5inch,6inch

LARGE SPACE INSIDE

Don't worry about not enough space

BATTERY PROTECTION BOARD

Don't have to worry about battery is destroyed

TAIWAN YFS BRAND SCREW

12.9 level screw

ALL PARTS

PHOTO ALBUM

Open post

GEP-ZX5

SUMMARY

Why do we have to develop this frame? We often think, how can I make a good performance, firm structure, is suitable for racing, also can very good complete freestyle action frame, we also have reference on the market some of the design of a good frame, we also have a try, continuous improvement, constantly thinking. Eventually, we make we think that is fine rack. The advantage of the rack will be introduced in detail below.

GEP-ZX using 3K carbon plate + aluminum alloy fastener. There are 3 kinds of wheelbase. GEP-ZX5:190MM, GEP-ZX4:170MM, GEP-ZX6:225MM. Frame all adopt 90 degree square X structure. The advantage is that the aircraft can fly in any direction flexible. The machine arm using 4MM 3K carbon plate thickness, width of only 14MM, to ensure the minimum drag. 2MM thickness is adopted on the upper plate and the upper plate of the fuselage main board and the upper plate, and the upper plate is made of 1.5mm thickness. One aluminum alloy fixings four machine arm, aluminum alloy piece is fixed the machine arm double strong and detachable arm machine, fast random replacement, extremely Crashworthiness. We finally chose to put the battery in the bottom of the fuselage, because the design of the camera position will be higher, if the battery in the lower body, the balance performance will be better. Camera positions we are very clever use of the fixed part, the angle can be adjusted, the maximum angle of 60 degrees, so that it is very good compatible with Runcam camera or GoPro camera.

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-ZX5
Weight:100g(include Aluminum parts)
Wheelbase:190MM 5’’
Size:160*175mm
Arms board:4mm
Main board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 /Naze32/ CC3D
Motor: 2204/2205/2206/2305/2306
Esc:20A-30A
Props:5inch
Battery:  3S 1300mAh ~ 4S 1300mAh

Features

  1. 3K high strength carbon board to ensure that the framework is strong
  2. Thanks to one piece of aluminum, The arm is stronger. Quick changing arm
  3. 5inch wheelbase only 190mm,very small
  4. This is “X” layout, Between each arm is 90 degrees. Each direction is very flexible
  5. The wind resistance is very small, but stay strong
  6. Forward direction can be selected
  7. The structure is strong, beautiful and light weight (100g, including all fixed parts).
  8. Motor position widened, better protection of motor
  9. Camera angle adjustable, adjustable 60 degrees
  10. The lens comes with fixed film, for the market of 95% CCD fixed lens

ALL PARTS

PHOTO ALBUM

Open post

GEP-RX5 Hawk

SUMMARY

Hawk, The dive speed of the prey is exciting.
This is the Hawk, The model name is GEP-RX5. Wheelbase 210mm, can be used for 5 inch propeller. “True X”Structure. This design is not difficult to see that the first two and two arm arm horizontal staggered, this helps to reduce turbulence, increase the efficiency of wind suction impeller.Gopro elements can be adjusted to adjust the range of 20-50 degrees, the lens is perfect support Hs1177, Hs1190, swift, Plus OWL and other most lenses. Lens distance 28mm. A reasonable layout, the factory comes with 10 WS2812B lights, support the microcontroller or flight control. Motor protection like a fish, to protect the motor to a certain extent, very good. Whole machine using YFS screws, the factory comes with a golden version. Random comes with BEC, 5V/12V PDB output. Save most of the time the player.

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-RX5 Hawk
Weight:99g
Wheelbase:210mm 5inch props
Size:190*180mm
Top board:4mm
Bottom board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 /Naze32/ CC3D
Motor: 2204/2205/2206/2305/2306
Esc:20A-30A
Props:5inch
Battery:  3S 1300mAh ~ 4S 1300mAh

Features

  1. 3K high strength carbon board to ensure that the frame is strong
  2. The front arm and rear arm horizontal staggered, increase flight efficiency, reduce turbulence, flight speed
  3. Rack comes with Gopro seat, adjustable angle, 20-50 degree
  4. 5 inch wheelbase 210mm
  5. YFS screws, 12.9 levels of hardness
  6. This is “X” layout
  7. Support HS1190, HS1170, Swift, OVL and other lenses
  8. The motor position widened, like fish, the collision is not easy to hit the motor
  9. Adjustable lens, 0-60 degree
  10. With a piece of PDB panels, integrated XT60, BEC (5/12v output)
  11. With a PDB, integrated XT60, BEC (5/12v output)
  12. With the development of LED lamp board, support flight control(cleanflight/betaflight) or work independently with MCU

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

THE MOTOR SEAT STAGGERED UP AND DOWN

To reduce disturbance airflow

ADJUSTABLE ANGLE, 0-60 DEGREE

The bigger the Angle

 GOPRO SEAT

Adjustable angle, 20-50 degree

RECEIVER SEAT

Guarantee the stability of the receiver

PDB INCLUDE XT60

Saved the space of the wire

LED LAMP BOARD

Support flight control(cleanflight/betaflight) or work independently with MCU

ALL PARTS

PHOTO ALBUM

Open post

GEP-TX5 Chimp

SUMMARY

This we all call him Chimp, model is GEP-TX. Careful players can see, GEP-VX and our Chimp is the same series of products, the appearance of a bit like a big brother GEP-VX. Chimp is a frame that can take the Gopro camera. Structure of "X Ture". Applicable to freestyle and competition, there are 3 versions of optional, 4 inch (wheelbase 180mm), 5 inch (wheelbase 210mm), 6 inch (wheelbase 230mm), are using 4mm thickness of the floor. The whole machine uses 3K ultra light carbon plate. Gopro elements can be adjusted to adjust the range of 20-50 degrees, the lens is perfect support Hs1177, Hs1190, swift, Plus OWL and other most lenses. Lens distance 28mm. A reasonable layout, the factory comes with 10 WS2812B lights, support the microcontroller or flight control. Motor protection like a fish, to protect the motor to a certain extent, very good. Whole machine using YFS screws, the factory comes with a golden version. Random comes with BEC, 5V/12V PDB output. Save most of the time the player.

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-TX5 Chimp
Weight:92g
Wheelbase:210mm  5inch props
Size:193*185mm
Arms board:4mm
Side board:2mm
Other board:1.5mm

Recommended

Flight Controller:F3 /Naze32/ CC3D
Motor: 2204/2205/2206/2305/2306
Esc:20A-30A
Props:5inch
Battery:  3S 1300mAh ~ 4S 1300mAh

Features

  1. 3K high strength carbon board to ensure that the frame is strong
  2. Rack comes with Gopro seat, adjustable angle, 20-50 degree
  3. 5 inch wheelbase 210mm, 4 inch wheelbase 180mm, 6 inch wheelbase 230mm
  4. YFS screws, 12.9 levels of hardness
  5. This is “X” layout
  6. Support HS1190, HS1170, Swift, OVL and other lenses
  7. The motor position widened, like fish, the collision is not easy to hit the motor
  8. Adjustable lens, 0-60 degree
  9. With a piece of PDB panels, integrated XT60, BEC (5/12v output)
  10. With a PDB, integrated XT60, BEC (5/12v output)
  11. With the development of LED lamp board, support flight control(cleanflight/betaflight) or work independently with MCU

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

Adjustable lens, 0-60 degree

Support HS1190, HS1170, Swift, OVL and other lenses
LED lamp board
support flight control(cleanflight/betaflight) or work independently with MCU

CAMERA POSITIONS

Camera positions adjustable angle, 20-50 degree

RECEIVER POSITION

Reserved exclusively for 2.4 g receiver position

BATTERY PROTECTION BOARD

Reduce the damage to the battery

MOTOR POSTIONS

Minimize the harm of motor

PDB INCLUDE XT60

Saved the space of the wire

PRECISE MACHINING

To reduce the error

YFS SCREW

YFS screws, 12.9 levels of hardness

ALL PARTS

PHOTO ALBUM

Open post

GEP-Mark1

SUMMARY

New GEP - Mark 1 is a multifaceted perfect FPV four axis fly frame, with high performance of Freestyle flying and excellent ability of racing.

The fuselage design, on the structure are X, we designed the machine arm isn't completely symmetrical. This is without changing the X structure, strengthen the fuselage hardness more effective.Benefit more than the fuselage streamline design, machine arm type is curve, the thickness is 4 mm, 13.7 mm, the narrowest maximize location is in the air volume.The scheme of motor three screw holes are fixed premises without loss of motor and the machine arm, enhance hardness of motor fixed position.The current problem of fission machine machine arm is easy to loose, we will spell schematic design to join, this interlocking, effectively reduce loose problem between the machine arm.Use high quality aluminum fuselage central fixed position, ensure the body strong.Roof thickness is 3 mm, more durable.And roof is streamlined design, so the middle period of narrow, reduce resistance.

Lenses can be adapted Hs1177 Hs1190, swift, OWL Plus most of the lens.3 mm thick roof, there are multiple levels of jack, can fit a variety of high-definition cameras installed.You need some EVA sponge to house their cameras.

PRODUCT BASIC INFORMATION

SPECIFICATIONS

Name:GEP-Mark 1
Weight:102g
Wheelbase:210mm
Arms board thick:4mm
Top board thick:3mm
Sider board thick:2mm
Other board thick:1.5mm

Recommended

Flight Controller:F3 /Naze32/ CC3D
Motor: 2204/2205/2206/2305/2306
Esc:20A-30A
Props:5inch
Battery:  3S 1300mAh ~ 4S 1300mAh

Features

  1. High strength 3K carbon board to ensure that the frame is strong
  2. Top thickness by 3 mm, more durable
  3. Fission structure of schemata
  4. With 35 mm fuselage space, enough space for players to choose electronic products
  5. Use 12.9 YFS screw
  6. High quality CNC fixed aluminum
  7. Streamlined fuselage design
  8. With a PDB, with a BEC (5/12v output, maximum 3A, maximum 500mA

DESIGN DRAWINGS

The design of the bit by bit

DETAILS

FISSION STRUCTURE OF SCHEMATA

Fission, but the difference is not big

HIGH QUALITY CNC FIXED ALUMINUM

Guarantee to the quality of the frame is huge

PDB & BUZZER

With a PDB, with a BEC (5/12v output, maximum 3A, maximum 500mA)

VELCRO STRAP PORT

Very convenient replacement

TO DESIGN THE  ARM

Widen the  arm weak place

WIDEN THE ANGLE OF THE CAMERA

Camera Angle 0 -  55 degrees

Camera Angle 0 55 degrees

True 'X' structure, good mobility. Wheelbase:210mm(motor to motor diagonal)

LARGE FUSELAGE LAYOUT

The fuselage height 35 mm, powerful space

The YFS screw

Use 12.9 YFS screw

ALL PARTS

PHOTO ALBUM

Posts navigation

1 2
Scroll to top
